Series 321
Specifications
| Part No | Status | WebEnabled | Accuracy | L | Type | Diameter |
|---|---|---|---|---|---|---|
| AC-321-001-ST | Stocked | 1 | ±1.5μm | 25mm | A | Ø7mm |
| AC-321-002-ST | Stocked | 1 | ±2μm | 50mm | A | Ø7mm |
| AC-321-003-ST | Stocked | 1 | ±2.5μm | 75mm | A | Ø7mm |
| AC-321-004-ST | Order In | 1 | ±3μm | 100mm | A | Ø8mm |
| AC-321-005-ST | Order In | 1 | ±3.5μm | 125mm | A | Ø8mm |
| AC-321-006-ST | Order In | 1 | ±4μm | 150mm | A | Ø8mm |
| AC-321-007-ST | Order In | 1 | ±4.5μm | 175mm | A | Ø8mm |
| AC-321-008-ST | Order In | 1 | ±5μm | 200mm | A | Ø8mm |
| AC-321-009-ST | Order In | 1 | ±5.5μm | 225mm | A | Ø8mm |
| AC-321-010-ST | Order In | 1 | ±6μm | 250mm | A | Ø8mm |
| AC-321-011-ST | Order In | 1 | ±6.5μm | 275mm | A | Ø8mm |
Note: ETA for Order In products is between 8-12 weeks.
