Series 334
Digital V-Anvil Micrometer
Measure the outside diameter of cutting tools (such as taps, reamers, end mills) with 3 or 5 flutes
Resolution: 0.001mm/0.00005"
Button: on/off, set, mm/inch,ABS/INC, data output
Automatic power off, Ratchet stop
Data output
Carbide measuring faces
Specifications
| Part No | Status | WebEnabled | Range | Accuracy | Setting Standards | Type | Flutes |
|---|---|---|---|---|---|---|---|
| AC-334-015-01 | Order In | 1 | 1-15mm/0.04-0.6" | ±4μm | 5mm | A | 3 |
| AC-334-020-01 | Order In | 1 | 5-20mm/0.2-0.8" | ±4μm | 5mm | B | 3 |
| AC-334-035-01 | Order In | 1 | 20-35mm/0.8-1.4" | ±5μm | 20mm | B | 3 |
| AC-334-050-01 | Order In | 1 | 35-50mm/1.4-2.0" | ±5μm | 35mm | B | 3 |
Note: ETA for Order In products is between 8-12 weeks.
